SP215

Description

The SP215 is an elegant and slim self-powered sublow system. The cabinet is constructed of a rigid, multilayer, cross grain birch plywood. Additionally braced with multiple reinforcement ribs and finished with a sturdy nano-armor™ coating.

Sound Projects SALC speaker management electronics and a proprietary 2500W CoolClass-D™ amplifier section power the two longstroke 15-inch drivers. This combination boasts an impressive 142dB SPL augmenting the low-end response of the full range and high/mid systems down to 30Hz, the deep sub you can feel.

The SP215 is cosmetically interchangeable with all SPX systems and will effortlessly add a tight kick to any rock concert as well as a fat old moog groove to a dance party.

Technical Data

Acoustical specifications
Drivers	2 x 15” High Power, low distortion, long excursion design. Double, impregnated spider and ventilated coil airgap for reduced power compression.
Freq. Reponse	30-60Hz/FR switchable: Sub Mode/FR (ext. LP filter)
Max. peak SPL @ 1m	142dB Peak level at 1M under half space conditions using pink noise with crest factor 4 (12dB)
Coverage angle	Omni-directional
Electrical specifications
Amplifier(s)	CCD™ technology
Output	2500W sine (SALC limited) Specified at 4Ω
Filter subsonic	30Hz, 2nd order
Low pass 4th order	60Hz / Full range (switchable) Fixed filter on request
Input impedance	20 kOhms balanced, 10 kOhms unbalanced
Output impedance	Hard-wired to input
Main voltage	230V (other on request)
Mains frequency	50 / 60 Hz
Idle	< 50VA
Full load	< 3000VA. DALC limited Ref. to continuous pink noise signal (12 dB crest factor within the specified range)
Protection	S.A.L.C. (Single Audio Logic Control)
Additional descriptive data
Cabinet construction	Cross grain laminated multiplex
Finish	Nano-armor™ coating
Weight (in kg)	72
Width (in mm)	450
Height (in mm)	1200
Depth (in mm)	600
Depth with wheels (in mm)	730
Rigging points	M20 polemount
Audio connectors	IEC XLR-3 in/out
Main connectors	Powercon in, powercon out
Max operating temp.	-10 to 40 C ambient
